OVERVIEW Heavy Duty Tandem Dual Gooseneck Big Tex 25GN Heavy Duty Tandem Dual Gooseneck The 25GN model comes standard with host of features including our Low Profile design and HD Adjustable Suspension. Low Profile Design: Pierced Integrated Frame: Adds Strength and Longevity Low Center of Gravity: Provides Improved Handling During Tow Shallower Load Angle: Safer and Easier to Load Lower Deck Height: Allows Taller Stacking of Loads Heavy Duty Adjustable Suspension: Heavy duty mechanical design reduces road shock to cargo Improves integrity, reliability, and durability Extended life for equalizer bushings, less wear, and lower maintenance Adjustable to ensure proper tire tracking Structural Details: 12'' I-Beam Frame & Neck 3'' Channel Crossmembers-Plasma Pierced Through Frame Torque Tube Standard on 28' (Flat Deck) & Longer 2 Side Bed Steps & Handles 1-1/4'' Pipe Chain Spool Between Stake Pockets 3/8'' Heavy Duty Rub Rail w/ Stake Pockets on 24'' Centers 3 Year Structural Warranty 5' Self Cleaning Dovetail w/ Variety of Ramp Options Dual Fold Over Ramps-Standard Equipped Where the Rubber Meets the Road: Premium Dexter Oil Bath 12,000# Axles ST 235/80 R-16 Load Range E Dual Radial Tires Forward Self Adjusting Brakes Complete Break-A-Way System w/Battery & Charger Mudflaps Spare Tire and Wheel More Standard Features: Lockable Toolbox Between GN Uprights Square Crank-Style Adjustable Coupler 50k Dual Two Speed Landing Gear (Bolted On) Sealed Modular Wiring Harness All Grommet Mount Sealed LED Lighting and Reflective Conspicuity Tape Spare Tire Mount 2'' Treated Pine Or Douglas Fir Floor (#2 or Better) 3/8'' Grd.70 Safety Chains w/Safety Latch Hook (2 each) Automotive Grade, Highly Decorative and Protective Finish Optional Ad-Ons: Electric Over Hydraulic Brakes Deck on Neck (Removable) Sliding Winch Track and Winches Underbody Tool Box(s) Additional Rear Ramps Available Third Fold Over Ramp Option Mega Ramps Center Pop-Up Straight-Deck Hydraulic Dovetail Lengths Available (Others by special order): 25GN 25' + 5' Dovetail $Call for Price 25GN 28' + 5' Dovetail $Call for Price 25GN 35' + 5' Dovetail $Call for Price 25GN 40' Straight Deck $Call for Price STANDARD EQUIPMENT 2-5/16" Ball Adjustable Coupler- Square Crank Type Dual Two Speed Landing Gear 50K Capacity (Bolted On) 102" Overall Width Low Profile Bed, Pierced- Beam Frame Design Lockable Toolbox Between GN Uprights (2) Side Bed Steps & Handles 3/8" Heavy Duty Rub Rail Stake Pockets Along Sides, 24" On Center 1-1/4" Pipe Chain Spools Between Tie Down Pockets Premium Brand Axles Oil Bath Hubs Forward Self Adjusting Brakes Heavy Duty 30,000# Adjustable Suspension by Dexter Axle Torque Tube Standard on 28 (Flat Deck) & Longer Grommet Mount Sealed Lighting L.E.D. Lighting Package Sealed, Modular Wiring Harness Spare Tire Mount (Top of Neck) 5 Dovetail w/ 5 Double Hinged Spring Assist Flip-Over Ramps Complete Break-A-Way System w/Charger Zip Breakaway Cable Radial Tires Mudflaps Spare Tire & Wheel-Standard Equipped OPTIONAL EQUIPMENT Category Description BODY Blackwood Pro Rubber Infused Floor BODY Removable Deck on the Neck- Bolt On (8 W x 6 L) BRAKES Air Brake Assembly w/ABS on Front, Spring Brake Chambers and Auto Slacks BRAKES Electric Over Hydraulic Brakes (Disc) BRAKES Electric Over Hydraulic Brakes (Drum) CARGO CONTROL 4" Sliding Winch CARGO CONTROL 4" Weld-On Winch CARGO CONTROL 4" x 30 Strap CARGO CONTROL 5/8" D-Ring (Each) CARGO CONTROL Low Profile Tool Box 12" x 18" x 36" (Side Mount) CARGO CONTROL Sliding Winch Track (Per 6 Section) JACKS Dual Electric Over Hydraulic Jacks by Stillwell RAMPS (2) 5 MEGA Ramps RAMPS 8 Rear Slide-In Ramps (Straight Deck Only) RAMPS No Dovetail Option (Deletes Dovetail and Ramps) TIRE/WHEEL Tire Upgrade (ST215/75 R-17.5 LR-H Dual) Includes Spare TIRE/WHEEL Tire Upgrade (ST235/85 R-16 LR-G Dual) Includes Spare **Available Sizes:** 8' | 10' | 12' | 14' | 16' | 18' | 19' | 20' | 22' | 24' | 25' | 27' | 30' Misc Trailers
