Standard Features Details GVWR 45,000 Overall Length 30'-0" Width 8'-6" Deck Height 34" Loaded Deck Length 25'-0" (20'-0" Level w/ 5'-0" Dovetail) Main Beam 12" Wide Flange Millroll Beam Side Beam 7" Channel Crossmembers 4" Wide Flange Millroll Beam Wheel Wells Oak Filled Dovetail 60" Wood Filled Draw Bar 3" Eye, Four Position Tongue Continuation of Mainframe Loading Ramps Spring Assist (24" x 60" Landing Gear Two-Speed 25,000lb Capacity Safety Chain 1/2" High Test Lashing Rings 5 Per Side Decking 1 3/4" Oak - Full Deck Suspension Hutch 3-Point, 3-Spring w/44,000 lb Capacity Springs Axles 22,500lb Capacity, 77 1/2" Track, Type 30 Brake Chambers Brakes 12 1/4" x 7 1/2" Shoes Tires 235/75R17.5 Low Profile Radials Wheels 8-Hole Steel Disc Wiring DOT Sealed Wiring Harness - LED Lights Toolbox Covered in Neck Paint Black Optional Features Apitong Wood Deck Air Ride Suspension Self Cleaning Dovetail Full Metal Dovetail Wood Filled Ramps Hydraulic Ramps Fold Over Ramps Additional Deck Length Additional Ramp Length Dual 2-speed LAnding Gear Polished Aluminum Rims Spare Tire Mounted (Hidden or Open) Rub Rail and Cuffs Single Point Suspension Metal Over the Wheel Wells Technical Drawing * All specifications are subject to change without notice.
