V-Nose Low Hauler Frame Type Steel Frame Hitch Type Tag Front Type V-Front Roof Type Flat Roof Length 12ft and 14ft Long Width 7ft Wide A-Frame Couplers 2-5/16in 10,000lb Coupler (1) Main Rails 2in x 3in Tube Main Rails Crossmember Spacing Crossmembers 16in On Center Crossmembers Z Crossmembers Beavertail 32in Recessed Beavertail (1) Height Standard Height Vertical Post Spacing Vertical Posts 16in On Center Vertical Posts 66-3/4in Hat Posts V-Nose Length 3ft V-Nose (1) Roof Bow Spacing Roof Bows 16in On Center Roof Bows Hat Section Roof Bows Lowhauler A-Frame V-Nose Lowhauler Tongue (1) Tongue Type Center Draw Bar (1) Safety Chains 7,800lb Silver Safety Chains w/Gold Hook (1) Jack Accessories Sand Pad (1) 2,000lb Tongue Jacks 2,000lb Top Wind Tongue Jack (1) Stabilizer Jacks Drop-Down Stabilizer Jacks (1) Weight 3,500lb Axle (2) Axle Width Wide Track Suspension Rubber Ride Suspension Starting Angle 22-1/2 Degree Up Angle Hub Type EZ-Lube Hubs Bolt Pattern 5 Bolt Pattern Stud Diameter 1/2in Studs Brake Type Electric Drum Brakes Brake Accessories Breakaway Kit (1) 15in Wheels 15in 5 Hole Gray 8 Spoke Steel Wheels (4) 15in Tires ST205/75R15 C Rated Tires (4) Wheel Accessories ABS Chrome Center Caps (4) 2-Tone 2-Tone - 24in Polished Aluminum (14) Color Black Finish .030 Aluminum Exterior (14) Exterior Walls Taped Exterior Sidewalls (1) Nose and Corners Chrome Nose (1) Nose and Corners Chrome Rear Corners (Must Inc. Chrome Rear Header) (1) Nose and Corners Chrome Rear Header (Must Inc. Chrome Rear Corners) (1) Stoneguard 24in ATP Stoneguard (1) Graphics Orange Lowhauler Graphics Kit (1) Sidewall Liner 5.2mm White Vinyl Sidewall Liner (14) Floor Decking Black Nudo Flooring with Backer (14) Ceiling Liner White Vinyl Ceiling Liner (14) D-Rings 5,000lb Square D-Ring (8) Rope Rings 500lb Surface Wall Mounted Rope-Ring (4) Wheel Chocks Removable Wheel Chock (2) Side Entry Doors - Bar-Lock/Flush-Lock 32 x 54 Side Entry Door - Bar/Flush Lock (1) Rear Ramp Doors - Extensions 16in Plywood Ramp Extension (1) Rear Ramp Doors - Extensions ATP Extension Covering-16 in wide (1) Rear Ramp Covering - Interior ATP Rear Ramp Door Covering (1) Rear Ramp Covering - Interior 3/4 Plywood Ramp Decking (96) (1) Rear Ramp Doors - Options .080 Ramp Door Hinge Cover (1) Rear Ramp Doors Max Size Rear Ramp Door - Standard Duty (1) Rear Ramp Covering - Exterior Black Ramp Exterior (1) 12v Lighting 12v Dome light (2) DOT Lighting License Plate Holder w/Logo and Separate Light (1) DOT Lighting Incandescent Tail Lights DOT Lighting Incandescent Clearance Lights DC Power 12v Surface-Mount Switch (1) Sidewall Vents
